Incoloy 800HT
Product properties:

Brand: KX-Alloy

Certification certificate: ISO9001:2015

Place of Origin: Danyang, Jiangsu, China

Product Description

Alloy Category: Corrosion Resistant Alloy

Substrate shape: Shaft wire/strip/straight strip

Alloy series: nickel-chromium iron alloy

Implementation standards: ASTM

Application fields: petrochemical industry, energy field, industrial field

Product description and application

Incoloy800HT is a fully austenitic low-carbon nickel-iron-chromium alloy of the same series as Incoloy800. The cobalt content in the alloy can be strictly controlled below 0.01%. Incoloy800HT is resistant to many corrosive media. Its high nickel content makes it very resistant to stress corrosion cracking in aqueous corrosive conditions. The high chromium content gives it better resistance to pitting and crevice corrosion cracking. This alloy has good corrosion resistance to nitric acid and organic acids, but has limited corrosion resistance in sulfuric acid and hydrochloric acid. In addition to the possibility of pitting corrosion in halides, it has good corrosion resistance in oxidizing and non-oxidizing salts. It also has good corrosion resistance in water, steam and mixtures of steam, air and carbon dioxide.

Incoloy 800HTComposition content
Fe:41.69%~47.79%
Ni:30%~35%
Cr:19.0%~23.0%
Mn≤1.5%
Si≤1.0%
Cu≤0.75%
AI:0.25%~0.6%
Ti:0.25%~0.6%
C:0.06%~0.1%
Vacuum induction furnace
Electroslag remelting
Product physical properties
Density

ρ=8.00 g/cm³

Melting temperature range

1350-1400 ℃

Mechanical properties

Test temperature/℃

Rm(MPa)

Rp0.2 Rm(MPa)

A(%)

Room temperature

≥550 ≥240 ≥30
